Chapter 16: Acid-Base Disorders In-Depth

Urine Nephrology Now: A Primer for Students in Nephrology

Andrew Bland, MD

Introduction

Acid-base homeostasis is fundamental to human physiology, with enzymatic function and metabolic processes requiring precise pH regulation. Deviations from the normal arterial pH range of 7.35-7.45 can have profound clinical consequences. It is critical to distinguish between acidemia/alkalemia (the state of the blood) and acidosis/alkalosis (the underlying process).

The Bicarbonate Buffering System

The bicarbonate buffering system is the primary extracellular buffer. Its governing equation is:

CO₂ + H₂O ⇌ H₂CO₃ ⇌ H⁺ + HCO₃⁻

The power of this system lies in the independent physiological control of its components: the respiratory system regulates CO₂ (acid) and the kidneys control HCO₃⁻ (base). Respiratory compensation is rapid (minutes to hours), while renal compensation is slow (days).

Systematic Approach to Interpretation (ABC Method)

Step A: Assess pH

Determine if acidemia (pH < 7.40) or alkalemia (pH > 7.40) is present.

Step B: Identify the Primary Disorder

Evaluate PCO₂ and HCO₃⁻. If the primary change aligns with the pH, it is the primary disorder.

  • Metabolic Acidosis: Low pH, Low HCO₃⁻
  • Metabolic Alkalosis: High pH, High HCO₃⁻
  • Respiratory Acidosis: Low pH, High PCO₂
  • Respiratory Alkalosis: High pH, Low PCO₂

Step C: Assess Compensation

Compensation is the body's attempt to normalize pH. Compensation is always incomplete; apparent overcompensation suggests a mixed disorder.

Compensation Rules and Formulas

  • Metabolic Acidosis (Winter's Formula): Expected PCO₂ = 1.5 × [HCO₃⁻] + 8 ± 2
  • Metabolic Alkalosis: PCO₂ increases by 0.7 mmHg for each 1 mEq/L rise in HCO₃⁻
  • Acute Respiratory Acidosis: HCO₃⁻ increases by 1 for each 10 mmHg rise in PCO₂
  • Chronic Respiratory Acidosis: HCO₃⁻ increases by 3.5 for each 10 mmHg rise in PCO₂
  • Acute Respiratory Alkalosis: HCO₃⁻ decreases by 2 for each 10 mmHg fall in PCO₂
  • Chronic Respiratory Alkalosis: HCO₃⁻ decreases by 5 for each 10 mmHg fall in PCO₂

The Anion Gap (AG)

AG = Na⁺ - (Cl⁻ + HCO₃⁻)

The normal anion gap range has narrowed to 8±2 mEq/L with modern analyzers. It's crucial to correct for albumin:

Corrected AG = Calculated AG + 2.5 × (4 - Albumin)

Causes of Elevated Anion Gap Metabolic Acidosis (AGMA)

MUDPILES: Methanol, Uremia, DKA, Propylene glycol, Isoniazid/Iron, Lactic acidosis, Ethylene glycol, Salicylates.

Causes of Non-Anion Gap Metabolic Acidosis (NAGMA)

NAGMA, or hyperchloremic metabolic acidosis, results from either the loss of bicarbonate or the addition of hydrochloric acid. The differential diagnosis can be organized using the mnemonic USEDCARP and further distinguished by the urinary anion gap (UAG).

The Urinary Anion Gap (UAG)

UAG = Urine Na⁺ + Urine K⁺ - Urine Cl⁻

The UAG serves as an indirect measure of urinary ammonium (NH₄⁺) excretion, which is the kidney's primary mechanism for eliminating acid. Since NH₄⁺ is excreted with Cl⁻, a high level of unmeasured NH₄⁺ (an appropriate response to acidosis) results in a high urine Cl⁻ and thus a **negative UAG**. Conversely, if the kidneys fail to excrete NH₄⁺, urine Cl⁻ will be lower, resulting in a **positive UAG**.

Differential Diagnosis of NAGMA using USEDCARP and UAG
UAG Result Pathophysiology Mnemonic (USEDCARP) Specific Causes
Positive UAG Renal Causes
(Impaired renal acid excretion)
Renal Tubular Acidosis (RTA)
Addison's Disease
Carbonic Anhydrase Inhibitors
Type 1 (Distal) RTA
Type 4 (Hypoaldosteronism) RTA
Type 2 (Proximal) RTA
Medications (Acetazolamide, Topiramate)
Negative UAG Extra-Renal Causes
(Bicarbonate loss, appropriate renal response)
Ureteral Diversion
Saline Administration (iatrogenic)
Enteral/Parenteral Nutrition (amino acid cations)
Diarrhea
Pancreatic or Biliary Fistula
Uretero-ileal conduit
Excessive 0.9% NaCl infusion
High-protein/cationic amino acid formulas
Most common cause of NAGMA
High-output GI losses

The Future of Acid-Base Assessment

The urinary anion gap is a valuable but indirect tool. Its use may decline in the future as direct measurement of urinary ammonium becomes more widely and rapidly available. Direct measurement provides a more precise quantification of the kidney's acid excretion response, eliminating the confounders that can affect the UAG (like the presence of other unmeasured anions such as ketoacids or drug metabolites).

Detecting Mixed Disorders

The Delta/Delta Ratio

ΔAG / ΔHCO₃⁻ = (Measured AG - 10) / (24 - Measured HCO₃⁻)

Management Principles

Management should focus on treating the underlying causes rather than simply normalizing pH. Bicarbonate therapy is controversial and generally reserved for severe acidemia (pH < 7.15) with hemodynamic instability, certain intoxications, or severe hyperkalemia.
